Seamless M22759/5-/31 Wires

SAE AS22759/5-/31

datasheet
Jump to AS22759/5, /6 specifications
Jump to AS22759/7, /8 specifications

Product Details

M22759 (SAE AS22759) wires are high-performance, medium- and high-temperature hookup wires with extruded PTFE or ETFE, or PTFE/polyimide tape insulators, and stranded conductors.

key features

  • Select types are available with highly abrasion-resistant insulation and/or high-strength conductors for maximum performance under mechanical stresses
  • Types with PTFE tape insulation are available with our unique Seamless Wrap PTFE tape insulation

applications

  • MIL-SPEC
  • Severe-environment aerospace applications, such as engine controls & SWAMP areas

Our in-house integrated engineering teams are ready to take on your greatest challenges.

Contact an Expert
Call 1-800-458-9960

Specifications: M22759/5, /6

Construction Details

M22759/5

M22759/6

For reduced-weight versions of these wires, see AS22759/7 and /8 below

InsulationExtruded PTFE with abrasion-resistant mineral fillers
Conductor/5: Silver-plated copper
/6: Nickel-plated copper
Colors• White preferred.
• All 10 basic colors & stripes are available to MIL-STD-104
Identificationto AS22759
Voltage Ratingto 600 V
Temperature Rating/5: -55 to 200°C
/6: -55 to 260°C
Products manufactured to this specification are ROHS COMPLIANT

Dimensions, Resistance & Weights: M22759/5 (Silver-Plated Conductor)

M22759 P/NAWG SizeStrandingConductor DiameterInsulation DiameterMaximum WeightMaximum ResistanceThermax P/N
MinMax
M22759/5-10-*1037/260.109 (2.77)0.172 (4.37)0.186 (4.72)48.0(71.4)1.19(3.90)10-AF3XT-3726
M22759/5-12-*1219/250.086 (2.18)0.153 (3.89)0.167 (4.24)34.5(51.3)1.81(5.94)12-AF3XT-1925
M22759/5-14-*1419/270.068 (1.74)0.136 (3.45)0.150 (3.81)25.0(37.2)2.88(9.45)14-AF3XT-1927
M22759/5-16-*1619/290.054 (1.38)0.120 (3.05)0.130 (3.30)18.0(26.8)4.52(14.8)16-AF3XT-1929
M22759/5-18-*1819/300.048 (1.22)0.105 (2.67)0.115 (2.92)14.0(20.8)5.79(19.0)18-AF3XT-1930
M22759/5-20-*2019/320.038 (0.98)0.090 (2.29)0.100 (2.54)10.0(14.9)9.19(30.1)20-AF3XT-1932
M22759/5-22-*2219/340.030 (0.77)0.080 (2.03)0.090 (2.29)8.0(12.0)15.1(49.5)22-AF3XT-1934
M22759/5-24-*2419/360.024 (0.61)0.070 (1.78)0.080 (2.03)6.0(9.0)24.3(79.7)24-AF3XT-1936
Dimensions in inches (mm). Weights in pounds/1000 feet (Kg/1,000 M). Resistance in Ω/1,000 feet (Ω/Km), @20° C.
All values are nominal unless otherwise indicated.
* Add color coding per MIL-STD-104.

Dimensions, Resistance & Weights: M22759/6 (Nickel-Plated Conductor)

M22759 P/NAWG SizeStrandingConductor DiameterInsulation DiameterMaximum WeightMaximum ResistanceThermax P/N
MinMax
M22759/6-10-*1037/260.110 (2.79)0.172 (4.37)0.186 (4.72)48.0(71.4)1.24(4.07)10-AF3XTN-3726
M22759/6-12-*1219/250.087 (2.21)0.153 (3.89)0.167 (4.24)34.5(51.3)1.89(6.20)12-AF3XTN-1925
M22759/6-14-*1419/270.069 (1.75)0.136 (3.45)0.150 (3.81)25.0(37.2)3.00(9.84)14-AF3XTN-1927
M22759/6-16-*1619/290.055 (1.40)0.120 (3.05)0.130 (3.30)18.0(26.8)4.76(15.6)16-AF3XTN-1929
M22759/6-18-*1819/300.048 (1.23)0.105 (2.67)0.115 (2.92)14.0(20.8)6.10(20.0)18-AF3XTN-1930
M22759/6-20-*2019/320.039 (0.99)0.090 (2.29)0.100 (2.54)10.0(14.9)9.77(32.1)20-AF3XTN-1932
M22759/6-22-*2219/340.031 (0.79)0.080 (2.03)0.090 (2.29)8.0(12.0)16.0(52.5)22-AF3XTN-1934
M22759/6-24-*2419/360.024 (0.62)0.070 (1.78)0.080 (2.03)6.0(9.0)25.9(85.0)24-AF3XTN-1936
Dimensions in inches (mm). Weights in pounds/1000 feet (Kg/1,000 M). Resistance in Ω/1,000 feet (Ω/Km), @20° C.
All values are nominal unless otherwise indicated.
* Add color coding per MIL-STD-104.

Specifications: M22759/7, /8

Construction Details

M22759/7

M22759/8

InsulationExtruded PTFE with abrasion-resistant mineral fillers
Conductor/7: Silver-plated copper.
/8: Nickel-plated copper.
Colors• White preferred.
• All 10 basic colors and stripes available to MIL-STD-104
Identificationto AS22759
Voltage Ratingto 600V
Temperature Rating/7: -55 to 200°C
/8: -55 to 260°C
Products manufactured to this specification are ROHS COMPLIANT.

Dimensions, Resistance & Weights: M22759/7 (Silver-Plated Conductor)

M22759 P/NAWG SizeStrandingConductor DiameterInsulation DiameterMaximum WeightMaximum ResistanceThermax
P/N
MinMax
M22759/7-8-*8133/290.164 (4.15)0.215 (5.46)0.225 (5.72)76.8(114)0.658(2.16)8-AF2XT-13329
M22759/7-10-*1037/260.109 (2.77)0.154 (3.91)0.162 (4.11)41.8(62.2)1.19(3.90)10-AF2XT-3726
M22759/7-12-*1219/250.086 (2.18)0.131 (3.33)0.137 (3.48)28.5(42.4)1.81(5.94)12-AF2XT-1925
M22759/7-14-*1419/270.068 (1.74)0.112 (2.84)0.118 (3.00)18.6(27.7)2.88(9.45)14-AF2XT-1927
M22759/7-16-*1619/290.054 (1.38)0.099 (2.51)0.105 (2.67)13.8(20.5)4.52(14.8)16-AF2XT-1929
M22759/7-18-*1819/300.048 (1.22)0.090 (2.29)0.094 (2.39)11.0(16.4)5.79(19.0)18-AF2XT-1930
M22759/7-20-*2019/320.038 (0.98)0.080 (2.03)0.084 (2.13)8.1(12.1)9.19(30.1)20-AF2XT-1932
M22759/7-22-*2219/340.030 (0.77)0.071 (1.80)0.075 (1.91)6.0(8.93)15.1(49.5)22-AF2XT-1934
M22759/7-24-*2419/360.024 (0.61)0.060 (1.52)0.064 (1.63)4.3(6.40)24.3(79.7)24-AF2XT-1936

Dimensions in inches (mm). Weights in pounds/1000 feet (Kg/1,000 M). Resistance in Ω/1,000 feet (Ω/Km), @20° C.
All values are nominal unless otherwise indicated.
* Add color coding per MIL-STD-104.

Dimensions, Resistance & Weights: M22759/8 (Nickel-Plated Conductor)

M22759/8-10-*1037/260.110 (2.79)0.154 (3.91)0.162 (4.11)41.8(62.2)1.24(4.07)10-AF2XTN-3726

M22759 P/NAWG SizeStrandingConductor DiameterInsulation DiameterMaximum WeightMaximum ResistanceThermax
P/N
MinMax
M22759/8-12-*1219/250.087 (2.21)0.131 (3.33)0.137 (3.48)28.5(42.4)1.89(6.20)12-AF2XTN-1925
M22759/8-14-*1419/270.069 (1.75)0.112 (2.84)0.118 (3.00)18.6(27.7)3.00(9.84)14-AF2XTN-1927
M22759/8-16-*1619/290.055 (1.40)0.099 (2.51)0.105 (2.67)13.8(20.5)4.76(15.6)16-AF2XTN-1929
M22759/8-18-*1819/300.048 (1.23)0.090 (2.29)0.094 (2.39)11.0(16.4)6.10(20.0)18-AF2XTN-1930
M22759/8-20-*2019/320.039 (0.99)0.080 (2.03)0.084 (2.13)8.1(12.1)9.77(32.1)20-AF2XTN-1932
M22759/8-22-*2219/340.031 (0.79)0.071 (1.80)0.075 (1.91)6.0(8.93)16.0(52.5)22-AF2XTN-1934
M22759/8-24-*2419/360.024 (0.62)0.060 (1.52)0.064 (1.63)4.3(6.40)25.9(85.0)24-AF2XTN-1936

Dimensions in inches (mm). Weights in pounds/1000 feet (Kg/1,000 M). Resistance in Ω/1,000 feet (Ω/Km), @20° C.
All values are nominal unless otherwise indicated.
* Add color coding per MIL-STD-104.
